AIR CONTAINERS

container banner

Air cargo containers are essential for global goods transportation, providing agility in international logistics. This guide offers information on specifications, dimensions, and capacities of different container types. Understanding these characteristics helps in choosing the ideal model for your freight needs, optimizing your operations.

Image 1
Image 2
Image 3

LD-3

Standard container for widebody aircraft, designed to maximize space in the lower cargo holds. Commonly used in Airbus A330 and Boeing 777.

Description Specification Description Specification
IATA ULD Code AKE Contoured Container Also Known As AKE, AVA, AVB, AVC, AVK
Forkable AKN, AVN, DKN, XKN Class Type 8
Recommended For A300, A310, A330, A340, B767, B777, DC10, MD11, L1011 Internal Volume 4.3 m³
Maximum Gross Weight 1,588 kg Dimensions 200 cm x 153 cm x 162 cm

LD-2

: Smaller contoured ULD, ideal for widebody aircraft like Boeing 747 and 767. It has less capacity compared to the LD-3.

Description Specification Description Specification
IATA ULD Code DPE Contoured Container Also Known As APA, DPA
Forkable DPN Class Type 8D
Recommended For B767 Internal Volume 3.4 m³
Maximum Gross Weight 1,225 kg Dimensions 156 cm x 153 cm x 162 cm

LD-1

Contoured container for transport in the lower holds of widebody aircraft. Similar to the LD-3 but with a slightly different shape to optimize space.

Description Specification Description Specification
IATA ULD Code AKC Contoured Container Also Known As AVC, AVD, AVK, AVJ
Forkable AVY Class Type 8
Recommended For B747, B767, B777, MD-11 Internal Volume 4.8 m³
Maximum Gross Weight 1,588 kg Dimensions 233 cm x 153 cm x 162 cm
Image 1
Image 2
Image 3

LD-6

A double LD-3, designed to occupy two compartments in widebody aircraft holds.

Description Specification Description Specification
IATA ULD Code ALF Contoured Container Also Known As AWD, AWF
Forkable AWC Class Type 6W
Recommended For A300, A310, A330, A340, B747, B777, DC10, MD11, L1011 Internal Volume 8.9 m³
Maximum Gross Weight 3,175 kg Dimensions 153 cm x 406 cm x 162 cm

LD-4

Similar to the LD-3 but with a slightly larger capacity, typically used in larger aircraft.

Description Specification Description Specification
IATA ULD Code AKE Contoured Container Also Known As AKN, AVN, DKN, XKN
Forkable AKN Class Type 6X
Recommended For B747 Internal Volume 4.4 m³
Maximum Gross Weight 1,588 kg Dimensions 198 cm x 156 cm x 162 cm

LD-3 Reefer

Refrigerated version of the LD-3, used for temperature-sensitive cargo such as food or pharmaceuticals.

Description Specification Description Specification
IATA ULD Code AKE Contoured Container Also Known As AKN
Forkable AVN Class Type 8T
Recommended For A300, A310, A330, A340, B747, B767, DC10, MD11 Internal Volume 4.3 m³
Maximum Gross Weight 1,588 kg Dimensions 200 cm x 153 cm x 162 cm
Image 1
Image 2
Image 3

LD-9 Refeer

Refrigerated version of the LD-9, ideal for transporting perishable or temperature-sensitive goods.

Description Specification Description Specification
IATA ULD Code RAP cool container on P1P Base Class Type 5
Recommended for 747, 767, 777, 787, DC-10, MD-11 lower hold Internal Volume 9.6 m³
Maximum Gross Weight 4,624 kg Dimensions 223 cm x 317 cm x 162 cm

LD-9

Large ULD used in freighters and widebody aircraft, with greater capacity than the LD-8.

Description Specification Description Specification
IATA ULD Code AAP Enclosed Pallet / P1P base Also known as AA2, XAG, XAV
Forkable AKN, AVN, DKN, XKN Class Type 5
Recommended for A300, A310, A330, A340, B747, B767, DC10, MD11, L1011 Internal volume 9.1 m³
Max gross weight 4,624 kg Dimensions 223 cm x 317 cm x 162 cm

LD-8

Wide container for transporting large volumes, commonly used in freighters.

Description Specification Description Specification
IATA ULD Code DQF Also known as ALE, ALN, DLE, DLF, DPQ, MQP
Forkable DPN Class Type 6A
Recommended for B767 Internal volume 6.85 m³
Max gross weight 2,450 kg Dimensions 153 cm x 317 cm x 162 cm
Image 1
Image 2
Image 3

LD-29

ULD designed to maximize space usage in larger widebody aircraft holds.

Description Specification Description Specification
IATA ULD Code AAU Contoured Container on P1P Base Class Type 5
Recommended for B747 Internal volume 14.2 m³
Max gross weight 6,033 kg Dimensions 224 cm x 318 cm x 472 cm

LD-26

Specialized container, typically used for bulky cargo in widebody aircraft.

Description Specification Description Specification
IATA ULD Code AAF Recommended for B747, B777, DC10
Max gross weight B747/DC10: 6,033 kg | B777/DC10: 4,626 kg Dimensions 318 cm x 406 cm x 163 cm

LD-11

Larger than the LD-6, primarily used in freighters for large volumes.

Description Specification Description Specification
IATA ULD Code ALP Rectangular Container Also known as ALD, AW2, AWD, AQZ, DWB, MWB
Class Type 6 Recommended for A300, A310, A330, A340, B747, B777, DC10, MD11, L1011
Refrigerated Versions RWB, RWD, RWZ Internal Volume 7.2 m³
Max Gross Weight 3,176 kg Dimensions 153 cm x 317 cm x 162 cm
Image 1
Image 2
Image 3

M-1

Main deck container for freighters, ideal for bulky cargo.

Description Specification Description Specification
IATA ULD Code AMA rectangular container on P6P base Also known as AMF, AMG, AMK, AMP, AQA, AQD and AQ6
Recommended for 747F, 747 Combi and 777F (main deck) Class Type 2
Max Gross Weight 6.804 kg Internal Volume AS1825: 17,6 m³
Tare Weight 350 kg Dimensions 243 cm x 317 cm x 243 cm

LD-39

Smaller container, frequently used for transporting special cargo in smaller aircraft.

Description Specification Description Specification
IATA ULD Code AMU Contoured Container on P6P base Class Type 2BG
Recommended for 747 (lower deck) Internal Volume AS1825: 15,9 m³
Max Gross Weight 5.035 kg Dimensions 243 cm x 472 cm x 162 cm
Tare Weight 290 kg Door Opening 305 cm x 152 cm

LD-29 Refeer

Refrigerated version of the LD-29, meant for temperature-controlled cargo.

Description Specification Description Specification
IATA ULD Code RAU contoured cool container on P1P base Class Type 5
Recommended for 747 (lower deck) Internal Volume 11,1 m³
Max Gross Weight 6.033 kg Dimensions 223 cm x 472 cm x 162 cm
Tare Weight 450 kg Door Opening 300 cm x 152 cm
Imagem 1
Imagem 2
Imagem 3

Demi

Half of an LD-3, used for smaller cargo in widebody aircraft.

Description Specification Description Specification
IATA ULD Code AYY contoured container on half pallet base Class Type 7
Recommended for 727F, 737F, 757F (main deck), 747F, 767F, 777F, DC-10F, MD-11F (main deck) Internal Volume AS1825: 5,8 m³
Max Gross Weight 3.016 kg Dimensions 157 cm x 223 cm x 200 cm
Tare Weight 80 kg

M-2

Similar to the M-1, but with reduced capacity for smaller aircraft or specific cargo.

Description Specification Description Specification
IATA ULD Code AGA 20-ft box container Also known as ASE
Class Type 1 Recommended for 747F, 747 Combi, 777F (main deck)
Max Gross Weight 11.340 kg Internal Volume AS1825: 33,7 m³
Tare Weight 1.000 kg Dimensions 243 cm x 605 cm x 243 cm

M-1H

Variant of the M-1 with a taller height, used for cargo requiring additional vertical space.

Description Specification Description Specification
IATA ULD Code AMD contoured Class Type 2H
Recommended for 747F, 747 Combi, 777F (main deck) Internal Volume AS1825: 21,2 m³
Max Gross Weight 6.800 kg/td> Dimensions 243 cm x 317 cm x 299 cm
Tare Weight 370 kg
Imagem 1
Imagem 2
Imagem 3

LD-7 with Folding Wings

Variant with foldable wings to optimize storage space when not in use.

Description Specification Description Specification
IATA ULD Code PAD P1P pallet with folding wings and net Also known as PAX and P1X
Recommended for 747, 777, 787, DC-10, MD-11 (lower deck) Class Type 5
Max Gross Weight 5.000 kg Internal Volume AS1825: 14 m³
Tare Weight 152 kg Dimensions 223 cm x 398 cm x 162 cm

LD-7 with Angled Wings

Variant with angled wings to accommodate contoured or irregular cargo.

Description Specification Description Specification
IATA ULD Code XAW P1P pallet with fixed-angle wings and net Class Type 5
Recommended for 747, 777, 787, DC-10, MD-11 (lower deck) Internal Volume AS1825: 14 m³
Max Gross Weight 5.000 kg Dimensions 223 cm x 398 cm x 162 cm
Tare Weight 170 kg

LD-7

Universal pallet used in widebody aircraft, designed for larger loads or custom volumes.

Description Specification Description Specification
IATA ULD Code P1P flat pallet with net Also known as PAA, PAG, PAJ, PAP, PAX, P1A, P1C, P1D and P1G
Recommended for Wide-body Aircraft: lower deck and main - Narrow-body Aircraft: 707F, 727F, 737F, 757F, DC8F, DC9F (main deck) Class Type 5
Max Gross Weight 4.626 kg Internal Volume AS1825: 10,5 m³ - Boeing: 10,7 m³
Tare Weight 105 kg Dimensions 223 cm x 317 cm x 162 cm
Imagem 1
Imagem 2
Imagem 3

PNA Half Pallet

A pallet similar to the PLA, but designed for specific loads or different layouts.

Description Specification Description Specification
IATA ULD Code PNA 767 half pallet with net Also known as PQP, FQF and PPC
Recommended for 767, 787 (lower deck) Class Type 8
Max Gross Weight 2.449 kg Internal Volume AS1825: 5,5 m³
Tare Weight 83 kg Dimensions 162 cm x 243 cm x 162 cm

PLA Half Pallet

Half-width pallet, ideal for smaller cargo or flexible distribution in aircraft.

Description Specification Description Specification
IATA ULD Code PLA half pallet with net Also known as PLB, FLA, P9A, P9B, P9P, P9R and P9S
Recommended for 747, 777, 787 (lower deck) - 707F, 727F, 737F (contoured main deck) Class Type 6
Max Gross Weight 3.175 kg Internal Volume AS1825: 7,1 m³
Tare Weight 91 kg Dimensions 153 cm x 317 cm x 162 cm

PMC/P6P Pallet

Standard pallet widely used in air transport, with dimensions of 96" x 125" (approximately 2.44 m x 3.18 m). Designed for general cargo on widebody aircraft, it is versatile and adaptable to different types of cargo.

Description Specification Description Specification
IATA ULD Code P6P 10ft flat pallet with net Class Type 2BG
Recommended for 747, 767, 777, 787, DC-10 and MD-11 Internal Volume 162 cm: 11.5 m³, 243 cm: 17 m³, 299 cm: 21.2 m³
Tare Weight 120 kg Dimensions 243 cm x 317 cm x 162 cm a 299 cm
Imagem 1
Imagem 2
Imagem 3

Type A Cage

Containment designed for transporting live animals, such as cattle or horses, ensuring safety and well-being.

Description Specification Description Specification
IATA ULD Code KMA sheep and goat pens on P1P base with net Class Type 3
Recommended for 747F (main deck), 767F, 777F, DC-10F, MD-11F Internal Volume AS1825 15,9 m³
Tare Weight Triple Deck: 610 kg Dimensions 223 cm x 317 cm x 243 cm

M-6 Twin Car Rack

M-6 configuration adapted for transporting two cars simultaneously.

Description Specification Description Specification
IATA ULD Code PRA 16-ft flat pallet with twin car racks as VRA Also known as PMA, P4A, P4M and PZA
Recommended for 747F, 747 Combi, 777F (main deck) Class Type 1P
Max Gross Weight 8.900 kg (The vehicle on the upper support must not exceed 1,800 kg) Support weight 130 kg (per pair)
Tare Weight 400 kg

HMA Stall

Specific containment for the safe transportation of horses or other large animals on the main deck.

Description Specification Description Specification
IATA ULD Code HMA horse box on P6P pallet base Class Type 2
Recommended for 747F (main deck), 767F, 777F, DC-10F and MD-11F Internal Volume AS1825: 18,4 m³
Max Gross Weight 3.500 kg Dimensions 223 cm x 317 cm x 162 cm
Tare Weight 1.310 kg
Imagem 1
Imagem 2
Imagem 3

MDP

A pallet specifically designed for use on the main deck of freighter aircraft. Its dimensions and design allow for the transport of bulky or heavy cargo, optimizing the available space.

Description Specification Description Specification
IATA ULD Code PRA 16-gt pallet with net Also known as PMA P4A, P4M and PZA
Recommended for 747F, 747 Combi, 777F Class Type 1P
Max Gross Weight 11.300 kg Internal Volume AS1825 27.6 m³
Tare Weight 510 kg Dimensions 153 cm x 317 cm x 162 cm

M-6 (118")

A wide pallet, 118" (approximately 3 meters) in length, primarily used on the main deck of freighter aircraft. Ideal for large cargo, including vehicles or industrial equipment.

Description Specification Description Specification
IATA ULD Code PGA 10-ft high, 20-ft flat pallet with net Also known as PGA, PGE, PGF, PSA, PSG, P7A, P7E, P7F and P7G
Recommended for 747 Combi, 777F, 747F (Only through the side loading entrance) Class Type 1
Max Gross Weight 11.340 kg Internal Volume AS1825 39.6 m³
Tare Weight 500 kg Dimensions 243 cm x 605 cm x 299 cm

M6

Wide container used on the main deck of freighters, typically for transporting vehicles or bulky equipment.

Description Specification Description Specification
IATA ULD Code PGA 20-ft flat pallet with net Also known as PGA, PGE, PGF, PSA, PSG, P7E, P7F and P7G
Recommended for 747F, 747 Combi e 777F Class Type 1
Max Gross Weight 11.340 kg Internal Volume AS1825: 33,7 m³
Tare Weight 500 kg Dimensions 243 cm x 605 cm x 243 cm

When opting for containerized freight transport, it is crucial to consider the safety of your cargo. International cargo insurance offers protection against loss and damage, ensuring that your logistics operation runs smoothly. For more information on protecting your cargo during transportation, check out our international cargo insurance service.

background

Customer Service

Our sales team is ready to assist you with your logistics needs and inquiries.


Contact Us
bannherfale
logo branco
